SR05LC

SR05LC

Status: Active
Package Type:
SOT-143
Packing Info:
3K/盘,180K/箱
Category:
Electrostatic protection diode
Product Detail
Part Number Product status Number of
Functions
Peak Pulse Current IPP (A) Package Junction Temperature Polarity Peak Power Dissipation
PPP(W)
Reverse Stand-off Voltage VRWM (V) Breakdown Voltage
VBR(V)
Maximun Clamping Voltage  VC(V) Maximum Reverse Leakage  IR (μA) Junction Capacitance CJ (pF) ESD level
SR05LC Active 3 5 SOT-143 150℃ Bi 125 5 6 25 1 0.9 Con 30KV/Air30KV
Packing Information
Part Number Package Type Packing Specification Marking Code Packing Info
SR05LC SOT-143 SOT-143 3K/盘,180K/箱
